12 best network cable testers
Network cable testers are essential tools used in the field of networking and IT infrastructure to diagnose, test, and inspect network cables. These devices help ensure that data cables, such as Ethernet cables, are properly installed and functioning correctly. Here's what you need to know about network cable testers:
Functionality: Network cable testers are designed to perform several critical functions, including:
- Continuity Testing: This function checks if all wires in the cable are properly connected and there are no breaks or short circuits.
- Wiring Configuration Verification: Cable testers can confirm that the wires are arranged correctly according to industry standards (e.g., T568A or T568B for Ethernet cables).
- Cable Length Measurement: Some testers can estimate the length of the cable, which is useful for planning and troubleshooting purposes.
- Cable Fault Detection: They can identify common issues like wire swaps, split pairs, or opens in the cable.
- Tone Generation and Tracing: Some testers can generate a tone on one end of the cable, allowing you to trace the cable's path in a bundle or through walls.
Types of Cable Testers: There are various types of network cable testers, including handheld testers, cable certification testers, and qualification testers:
- Handheld Testers: These are portable and typically used for basic testing and troubleshooting.They are handy for quickly verifying cable connections.
- Certification Testers: These advanced testers are used for certifying cabling installations against specific standards, such as those defined by TIA/EIA (Telecommunications Industry Association/Electronic Industries Association).
- Qualification Testers: These testers are less expensive than certification testers and are used to determine if a cable installation can support a specific network speed, such as Gigabit Ethernet.
Usage Scenarios: Network cable testers are employed in various situations:
- During cable installations to ensure proper connectivity before finalizing the installation.
- In maintenance and troubleshooting to identify and resolve cable-related issues quickly.
- To validate the performance of structured cabling systems in commercial buildings and data centers.
Benefits: Using network cable testers offers several advantages:
- Saves time and effort by pinpointing cable issues without the need for trial and error.
- Helps prevent network downtime and performance issues by identifying and resolving cable problems.
- Provides confidence that cabling installations meet industry standards and can support desired network speeds.
User Interface: Cable testers typically feature easy-to-read displays, audible alerts, and intuitive user interfaces to simplify the testing process. Some advanced testers may have touchscreen displays for enhanced usability.
Portability: Handheld cable testers are often compact and battery-powered, making them suitable for fieldwork and on-site troubleshooting.
In conclusion, network cable testers are invaluable tools for IT professionals and network technicians. They ensure the integrity and functionality of network cables, which is essential for maintaining reliable network connections and preventing network issues. These testers come in various types and offer different features to meet the needs of different users and scenarios.
Below you can find our editor's choice of the best network cable testers on the market
Wire Tracker, ELEGIANT RJ11 RJ45 Cable Tester Line Finder Multifunction Wire Tracker Toner Ethernet LAN Network Cable Tester for Network Cable Collation, Telephone Line Tester, Continuity Checking
ELEGIANT
User questions & answers
| Question: | All i need to do is check ethernet wall connectors to make sure there is a signal in the line. will this do that? i don't need a device that sends a s |
| Answer: | This is to locate by one end sending the signal and the other locating it. Best way to see if you have an intern signal is to use a laptop with an Ethernet cable connected to it then plug it in to the Ethernet jack and see if you pull an ip address or able to get online. If you do not have the Ethernet jacks labeled with id numbers of where they are located on a patch panel, you will need the cable tester to find where the cable is connected on both ends. Good luck and I hope this helps. |
| Question: | can this be used to trace wire behind a wall |
| Answer: | Most toners can trace a wire in a wall as long as you can put the tone generator on 1 end. I used the fluke PRO3000 to find a missing plug covered by sheetrock by turning off circuit and placing clips on wires of a outlet then waving wand by a wall area even though you should see bulge of box behind drywall in new construction. |
| Question: | Any suggestions, item just arrived, tested it and it won't even tone a two foot cable, did I get a dud |
| Answer: | Re Elegiant EN61010-1 multi-function wire tracker (1/8/18): Received it after reading positive reviews, but this is an INEXPENSIVE tracer - don't expect too much. Instructions, in broken English, are nearly useless. SEVERAL CAUTIONS: NEVER test a "live" circuit, except the telephone line (see instructions; a ringing phone line can have 110 volts, so be careful!) The Probe unit is VERY sensitive, and the probe tip is almost a microphone - ANY contact will transmit a "bang" to the ear plugs - ALWAYS turn volume down to start (clockwise = lower volume on this probe!). Mine will generate a tone (set sending unit to SCAN, verify by scan LED lighting on sending unit). Turn on receiver unit with probe (red LED will light up). While it appears the probe has a loudspeaker, mine doesn't work or may not exist. You must use their specific earplugs. Warning: turn volume to minimum (CLOCKWISE on this unit!). To test unit operation, plug the RJ11 adapter (with the red and black clips) into the RJ11 jack on the sending unit - no need to connect the clips to anything for this test. Wearing the earplugs (and volume turned down, CLOCKWISE), press AND HOLD the SCAN button on the probe (green LED will light), and move the probe tip close to either the red or black clip ends. Then SLOWLY turn the volume control COUNTER-CLOCKWISE (increase the volume) ... and you should hear a warbling tone in the earplugs. This warbling tone is what you are looking for - it gets loudest as the probe tip moves closest to the wire the clip of the sending unit is attached to. With mine, the BLACK clip transmits a louder signal, but the RED clip will also transmit a signal. It is not necessary to connect the second clip to an adjacent wire or a ground to transmit and receive the tone, but in some cases it could help - try it initially with only the black clip on a single wire, then try by clipping the red clip to the other wire of the pair, or to a ground, to see what works best in your situation. To test continuity, set switch on emitter to "Cont". Using the RJ11 adapter with red and black clips, touch the clips together and the green CONT LED light will illuminate to verify a circuit (continuity). There is no tone to confirm, just the tiny LED. The TONE function does not generate a tone, it simply sets the unit to test a phone line (confusing!). The NETWORK function requires the ethernet cable to be plugged into the sending unit on one end, and the probe unit on the other. Pressing the TEST button on the emitter unit will then test all the wire connections - but nothing will happen until you press that TEST button. When you do, each wire is tested individually, with verification by LED simultaneously on both the sender and probe units. Short circuits will appear as solid or blinking lamps. Hope this answer clarifies for others! The manufacturer NEEDS TO CLARIFY INSTRUCTIONS!!! |
| Question: | Can I trace/test coaxial cable with this |
| Answer: | Should be able to find a scrap piece of coax with an end already crimped on it. Strip the opposite end, leaving the core and shielding exposed. Hook up the alligator clips to the outside shield, and another to the inside core. You should be able to test the cable like others. |
Klein Tools VDV501-852 Cable Tester with Remote, VDV Scout Pro 3 Test Kit Locates and Tests Voice, Data and Video Cables
Klein Tools
Product description
The Scout Pro 3 Tester with Location Remote Kit is a versatile cable tester that locates and tests voice, data and video cables. Identify multiple cable runs with 18 location mapping remotes (included). Test for Power over Ethernet (PoE) and measure cable length. This kit verifies accurate cable installations each time. Backlit display assists in reading results in lower light. Test voice (RJ11/12), data (RJ45) and video (F-connector) coax cable. Identify multiple cable runs with location mapping ID remotes. Tester detects, identifies and tests Power over Ethernet (PoE). Identify 18 RJ45 and 18 F-connector drop locations with large easy-to-read numbers. Detect, identify and test Power over Ethernet (PoE). Backlit LCD screen displays cable length, wiremap, cable ID and test results. Hub blink mode to identify port location on a hub or a switch. Includes 1 Self-storing Test + Map Remote (31), 18 RJ45 LAN locator remotes, 18 F coax locator remotes, 2 female-to-female coax adapters and a 9V battery. Convenient carrying case keeps everything together and in reach. For more than 160 years, Klein Tools has manufactured premium-quality, professional-grade hand tools that deliver the performance, durability and precision needed to get the job done right. Our family of engineers, workers and craftsman continue to put six generations of expertise into every tool we create by using only the highest quality materials, superior workmanship, and keeping manufacturing as close to home as we can. Klein isn't just the name of our company, it's also our family name. And since we're an American company that's family-owned and family-run, you know you can count on us to be here tomorrow. Klein Tools doesn't just make great products, we make great products that stand up to the demands of the professionals who use them every day . Since 1857.
- Cable tester for voice (RJ11/12), data (RJ45) and video (F-connector) coax connections
- Self-storing Test + Map Remote (#1) tests, maps and IDs a cable run in a single step
- Power over Ethernet Tester that displays PoE wire and Voltage
- Trace cables, wire pairs and individual conductor wires with a tone generator
- Measures cable length up to 2,000 feet (610 m)
User questions & answers
| Question: | Can this do POE |
| Answer: | If you mean, can it detect the DC power going to the device, the answer is Yes. There is a separate port on the side for POE. |
iMBAPrice - RJ45 Network Cable Tester for Lan Phone RJ45/RJ11/RJ12/CAT5/CAT6/CAT7 UTP Wire Test Tool
iMBAPrice
- Automatically runs all tests and checks for continuity, open, shorted and crossed wire pairs. Visible LED status display.
- Cable state testing (2-wire): Line DC detecting, anode and cathode determination,Ringing signal detecting open, short and cross circuit testing
- Cable Type: RJ11 Telephone cable and RJ45 LAN cable
- Connectors: Ethernet Cat 5, Ethernet Cat 5e, Ethernet Cat 6, Ethernet Cat 7, RJ11 6P and RJ45 8P
- Power Source: DC9V Battery Required (not included)
User questions & answers
| Question: | Does it estimate distance to break |
| Answer: | No. This is just tool is just basically a Continuity Tester that allows you to test connections on between two end to insure ALL EIGHT (Internet)/FOUR (Hardline Telephone) wires ARE..in fact connected between them. The Remote feature is used when you want to check Continuity of connectors already installed from one room to another. This feature is the best for me. Although..Pay attention to the statement above that the Cable Connections being tested should not be Powered (Such as Phone Lines) or damage to the tester may occur. There IS NO tool that can estimate the distance to a Potential Break that I am aware of. Pulling and replacing Old wire with new may be the only option there. |
| Question: | There are 3 different testers for sale, which do I need to test my cat 6 cables installed by electrician and my own cables? Connection is spotty |
| Answer: | One that does rj45. Cat6 cables have rj45 connectors. This tester will only tell you if the wires are connected in the proper order, not if the quality of the connection is good enough. That requires a much more expensive tester. |
| Question: | what does is mean the lights just keep sycaling |
| Answer: | When you are doing the test, the lights continue to go through the cycle 1, 2, 3, etc., testing the pairs. If there is a problem with a pair, the lights cycle will indicate by going 1, 2, 3, 4, 6, 5, etc., indicating a problem between pair 5 & 6. You might not see that the first time so the lights will just continue to run through the sequence so you can continue to see where the problem pair is located. It just means that the lights continue until you turn off the test. It works great and it’s very simple to use. Once you use it, you will understand what the “sycaling” means. It just doesn’t do it once and then stops, it continues to sycaling through. |
| Question: | I need to define which cable is linked to each room in house as they all terminate in a single box in closet. Will this define which cable is which |
| Answer: | Yes, but it will require patience and a bit of time. First unplug all LAN cables from your switch or router in the closet. Also unplug any computers or printers or switches in all of the rooms. This tester is not meant to test “live” cables. If you are testing jacks (not terminated cables) you will need a tested jumper cable for each end (test the jumpers first). Connect the master CT468 to one of the lines in the closet and turn it on. I recommend the “on setting” to save time (the S is for slow). Then go room to room with the CT468 remote and plug the remote in (if testing jacks plug in the known good jumper cable). It should light up in a couple of seconds if that line in the closet goes to that room. Once you get lights on the remote you have identified which room corresponds with the cable the CT468 master is connected with in the closet. Let the lights cycle at least two times to check for continuity on all pairs in that cable. If one or more of the lights do not light up or they do not light up in order (1 then 2 then 3 then 4 then 5 then 6 then 7 then 8) then you have a problem in that cable. Note G is only for Shielded Twisted Pair (STP) cables, which are rarely used in a home environment. You will need to repeat this process for each cable in the closet and each room. Don’t forget to label each end. Good luck and God bless. V/R Steve |
Product features
Easy to Carry
Portable handheld design makes this easy to use.Even if the cable is pre-installed it can be test with detachable part.
Cable Tester For Network (RJ45)& Telephone(RJ11)
RJ11 Telephone cable and RJ45 LAN cable both can be tested with the tester.it supports RJ45/RJ11/RJ12/CAT6/CAT7.
Error Free Operation
Complete error free operation with DC detecting anode and cathode determination,ringing signal detecting open,short and cross circuit testing.
Klein Tools VDV226-110 Wire Crimper / Wire Cutter / Wire Stripper Pass-Thru Modular All-in-One Tool for Video, Telecom, Datacom and more
Klein Tools
Product description
Premium, long lasting tool cuts, strips and crimps CAT3, CAT5e and CAT6/6A cable using RJ11/RJ12 standard and RJ45 Pass-Thru connectors. Pass-Thru technology significantly reduces prep work time; wiring diagram on the tool helps eliminate rework and wasted materials. Compact, non-slip comfort grip reduces hand strain and stores easily. For use with Klein Pass-Thru Connectors (in packs of 10, 50 or 200). Versatile design cuts, strips and crimps paired-conductor cables. Compact, non-slip grip reduces hand strain for optimal use. Designed for use with Klein Tools pass-thru connectors. Full-cycle ratchet mechanism ensures complete connector termination. On-tool wiring guide helps minimize wiring errors. Cable parameters: 28-22 AWG flat or round; solid or stranded telephone and data. Rubber grip for added comfort. Ratcheting locking mechanism. Use with Klein Tools Pass-Thru Connectors. Not for use with standard (non Pass-Thru) connectors. Replacement blade set available (VDV999-076). For more than 160 years, Klein Tools has manufactured premium-quality, professional-grade hand tools that deliver the performance, durability and precision needed to get the job done right. Our family of engineers, workers and craftsman continue to put six generations of expertise into every tool we create by using only the highest quality materials, superior workmanship, and keeping manufacturing as close to home as we can. Klein isn't just the name of our company, it's also our family name. And since we're an American company that's family-owned and family-run, you know you can count on us to be here tomorrow. Klein Tools doesn't just make great products, we make great products that stand up to the demands of the professionals who use them every day . . . Since 1857.
- Modular crimp-connector installation tool for voice and data applications with Pass-Thru RJ45 connector plug
- Wire stripper, crimper, and cutter all-in-one tool for paired-conductor data cables
- Trims flush to end face of connector eliminating unintended contact between conductors
- Crimps and trims Klein Tools RJ45 Pass-Thru Connectors
- Crimps 4, 6 and 8 position modular connectors (RJ11/RJ12 standard and RJ45 Klein Tools Pass-Thru)
User questions & answers
| Question: | Can you use this for non pass through connectors |
| Answer: | Yes. Works fine for non pass through connectors. |
| Question: | Do you have to use the Klein pass thru connectors or will these work with any pass thru RJ45 connector |
| Answer: | Good question! Some buyer have tried the C5 and C6 non-pass thru Mod Plugs, but now are using Klein's Pass-Thru™ connectors. If cost is issue, the Klein Pass-Thru™ Clear Mod Plug, now comes in a 200 Pack - VDV826-763. Hope this helps. We have all Klein Pass-Thru™ Mod Plugs - C5, C6, and 3PC Clear Modular Data Plug are stock. |
| Question: | Will these crimpers work with other vendors ez connectors / pass through rj45 connectors. example (platinum tools ez-rj45 cat6 connectors |
| Answer: | My personal experience - I bought these connectors: https://amzn.to/2FWDmpL "RJ45 CAT6 Passthrough Connectors (50 PCS),Gold Plated 3 Micron 3u, High Performance 3 Prong Pins (CAT6/50 PCS)" - they seem to work ok. However, although the cable works fine my tester says it has a short. Not sure if it has to do with the connectors, the cable (cat5), or the tester being finicky. But the cable does work. |
| Question: | What's the key difference between the $20 (226-107) crimper and the $45 (226-110) crimper |
| Answer: | To me it looks like the 107 doesn't do the pass through connectors. It is smaller in size that the 110 model it might fit your pocket better than the 110. But since I only use the pass through connectors the 107 wouldn't work for me. |
Product features
Pass-Thru Modular Wire Crimper, All-in-One Tool Cuts, Strips, Crimps, Fast and Reliable
Premium, long lasting tool cuts, strips and crimps CAT3, CAT5e and CAT6/6A cable using RJ11/RJ12 standard and RJ45 Pass-Thru connectors. Pass-Thru technology significantly reduces prep work time; wiring diagram on the tool helps eliminate rework and wasted materials. Compact, non-slip comfort grip reduces hand strain and stores easily. For use with Klein Pass-Thru Connectors (in packs of 10, 50 or 200).
Advanced Cable Tester with PoE Multifunction Wire Tracker Network Cable Tester for te Toner Tool Kit with Bag Probe Audio Tone for LAN CAT5 CAT6 Tracker Underground Telephone Line Finder Home Repair
NOYAFA
- Main Function : Detecting PoE voltage, current, power, PSE standards Power supply modes, Verify RJ45 cables
- 1. Three scan modes selectable: AC filter mode/ Analog mode/ PoE mode
- 2. Detect AC voltage presence (50V-1000V). Test physical status for STP, UTP lan cable.
- 3. Measure cable length accurately , the range is 200m.
- 4. Hub blink for locating network port by the flashing port light on Hub / Switch. Available to 10M/100M/1000M Hub/ switch.
- 5. PoE testing : identify which pins are providing power and detect how much voltage, identify which the type of PSE (at/af standard)
User questions & answers
| Question: | Does it trace coax cable? i’ve had no luck in both digital and analog modes. maybe my rj11 adaptor or unit is defective |
| Answer: | it' can Test physical status for STP, UTP lan cable. can't test trace coax cable |
| Question: | Puede trabajar con PoE? Es decir batería conectada en el tester |
| Answer: | Hello,this model can test for POE,the voltage data,the POE standard,and it also can tracing cables which connacted with POE switch. the power supply is 9v battery for the receiver,3pcs 1.5v AAA batteries for the main tester. |
Klein Tools VDV501-851 Cable Tester Kit with Scout Pro 3 for Ethernet/Data, Coax/Video and Phone Cables, 5 Locator Remotes
Klein Tools
Product description
The Scout Pro 3 Tester Starter Kit is a versatile cable tester that locates and tests voice, data and video cables. Identify multiple cable runs with included location mapping remotes. This kit verifies accurate cable installations each time. Backlit display assists in reading results in lower light. Test voice (RJ11/12), data (RJ45) and video (F-connector) coax. Identify multiple cable runs with location mapping ID remotes. 9V battery included. Hub blink mode to identify port location on a hub or a switch. LanMap and CoaxMap Location Remotes (5 each) map and ID multiple cable runs in a single step. Includes voltage warning, shield detection, auto power off, low battery indicator and a self-storing remote. Auto Power-off feature to conserve battery life (9V included). Kit includes: Scout Pro 3 Tester, self-storing remote, LanMap RJ45 locator remotes, CoaxMap F-connector locator remotes, coax F-connector, manual and 9V battery. For more than 160 years, Klein Tools has manufactured premium-quality, professional-grade hand tools that deliver the performance, durability and precision needed to get the job done right. Our family of engineers, workers and craftsman continue to put six generations of expertise into every tool we create by using only the highest quality materials, superior workmanship, and keeping manufacturing as close to home as we can. Klein isn't just the name of our company, it's also our family name. And since we're an American company that's family-owned and family-run, you know you can count on us to be here tomorrow. Klein Tools doesn't just make great products, we make great products that stand up to the demands of the professionals who use them every day . Since 1857.
- Cable tester tests voice (RJ11/12), data (RJ45) and video (coax F-connector)_ terminated cables with clearly defined results
- Measure cable length up to 2000 feet (610 m)
- Test for Open, Short, Miswire or Split-Pair faults
- Backlit LCD screen displays cable length, wiremap, cable ID and test results
- Trace cables, wire pairs and individual conductor wires with multiple style tone generator (requires analog probe Cat. No. VDV500-123; sold separately)
User questions & answers
| Question: | What is the biggest difference between the scout pro 2 and |
| Answer: | The scout 3 has Way more features and multiple identification points also detect whether there’s a hub at the end and a derects cable like |
| Question: | Can the tone pattern be changed or only the frequency |
| Answer: | They laying only frequenciey |
| Question: | Can you test bnc cables with this. if so , do i need to buy adapters to do so |
| Answer: | The starter kit does not come with any BNC connectors. But if you get f to bnc adapters I don’t see why not. |
| Question: | Does this measure cable length |
| Answer: | yes, it measures cable length. |
Product features
Cable Tester Kit with Scout Pro 3 for Ethernet / Data, Coax / Video and Phone Cables, 5 Locator Remotes
The Scout Pro 3 Tester Starter Kit is a versatile cable tester that locates and tests voice, data and video cables. Identify multiple cable runs with included location mapping remotes. This kit verifies accurate cable installations each time.
Klein Tools LAN Explorer Data Cable Tester with Remote VDV526-100
Klein Tools
Product description
Klein Tools LAN Explorer™ Data Cable Tester with Remote
- Cable tester with single button testing of RJ11, RJ12 and RJ45 terminated voice and data cables
- Tests CAT3, CAT5e and CAT6/6A cables
- Fast LED responses indicate cable status (Pass, Miswire, Open-Fault, Short-Fault, and Shield)
- Test remote stores securely in tester body
- Compact tester easily fits in your pocket
User questions & answers
| Question: | Will plugging this into a POE switch kill this tester |
| Answer: | I don’t know if it will “kill” it. But I wouldn’t recommend it. Not sure why you would do that. It’s only meant to test open cables. |
| Question: | Does the unit come with a dongle to test ethernet cables from a single point |
| Answer: | You have to hook up the test remote that stores securely in tester body to the opposite end of the Cat 5 cable and then test the cable with the tester body. If you don't hook up the test remote at the opposite end of the cable the tester body cannot check the cable. The slang name for the test remote that stores securely in tester body is a "Whistle". |
| Question: | How does this compare to the klein lan scout jr. network tester (vdv526-052)? this is half the price but looks to have more features |
| Answer: | The Lan Explorer Data Cable tester is a little more than an ohm meter. The Scout maps the cable giving you true cable alignment as per, "it ohmed out." But, neither are the $10K Lan Meter from Fluke. Do you want to pay double for 3 times the information. I do not own either tool but will be purchasing the Scout soon. (Owner of defunct ABK FiberOptics, my work force grew up and move away. Installed over 1,000 connections for my employer on one network with no errors.} |
| Question: | Does it test for reverse or split pairs, if not, does it show up as pass or miswire |
| Answer: | Here is what the manual says... FAULT INDICATORS 8 MISWIRE: Illuminates if the cable is not wired to one of the cabling standards shown below, or if the conductor wire order on the near end do not match the conductor wire order on the opposite end, i.e. if Pin 1 on near end is wired to Pin 2 on the far end. OPEN: Illuminates if one or more of the conductor wires on the near end are not terminated properly on the far end, or if any of the near-end contact pins are not properly terminated. SHORT : Illuminates when two or more conductor wires make contact with each other. SHIELDED INDICATOR 4 Illuminates when a shielded (ground wire or foil) data cable is properly connected at both ends, either by ground wire or by foil. NOTE: • When “OPEN” and “MISWIRE” exist simultaneously, only can be judged as “OPEN”. • When “SHORT” and “MISWIRE” exist simultaneously, only can be judged as“SHORT” • When “OPEN” and “SHORT” exist simultaneously for one wire, only can display one status. If “OPEN” first then “SHORT”, judge as “OPEN”; If “SHORT” first then “OPEN”, judge as “SHORT”. • If only one fault (“OPEN” or “SHORT”) happens to one wire. For example, wire#1 is open, wire#4 and wire#5 are shorted, then both “OPEN” and “SHORT” can be detected and displayed. NOTE: A Cross-Over Wired cable will flash the MISWIRE and PASS LEDs simultaneously. On an RJ12-terminated wire with pin 1 and 6 open faults, "RJ11 PASS" will be the response. |
Product features
Network LAN Cable Tester, VDV Tester, LAN Explorer with Remote
This simple data cable tester tests RJ11, RJ12 and RJ45 terminated voice and data cables for Miswires, Open-Faults, Short-Faults and Shield. Instant LED responses indicate cable status. The test remote stores securely in the tester body.
Klein Tools VDV526-052 Cable Tester, LAN Scout Jr. Network Tester / Continuity Tester for RJ45 Data Cable Twisted Pair Connections
Klein Tools
Product description
This compact cable tester is an easy-to-use tester that saves time and money on the job. The LAN Scout Jr. tests continuity on twisted pair data wiring connections. An integrated tone generator supports multiple tones and control of the pins carrying the tone. The self-storing remote makes this tool easy to store and locate. Easy-to-use tester tests twisted pair data wiring connections. Jr. tester with self-storing remote, has large display. Features dual function button and rubber molding. Rubber molding for comfort. Self-storing remote. For more than 160 years, Klein Tools has manufactured premium-quality, professional-grade hand tools that deliver the performance, durability and precision needed to get the job done right. Our family of engineers, workers and craftsman continue to put six generations of expertise into every tool we create by using only the highest quality materials, superior workmanship, and keeping manufacturing as close to home as we can. Klein isn't just the name of our company, it's also our family name. And since we're an American company that's family-owned and family-run, you know you can count on us to be here tomorrow. Klein Tools doesn't just make great products, we make great products that stand up to the demands of the professionals who use them every day ... Since 1857.
- Cable tester tests the continuity of twisted pair data wiring (RJ45) connections
- Displays wire map
- Easy to use, compact tool saves time and money on the job
- Dual function button- operates test functions and tone generator
- Large display for easy identification
User questions & answers
| Question: | Will this work with the VDV |
| Answer: | This is really just a single purposes tester. Works great for verification of Jack installation and its wire. Also works great for single line tracing. The "doggle" detaches from the bottom of the unit then one end of the line plugs into it. The other end of the line plugs into the tester. Verifies each wire in the line is or isn't correct. |
| Question: | Will this test ethernet signal quality and speed |
| Answer: | Hello I'm back again I did some further testing and further research this tool absolutely will not do a speed test. This is what you're looking for click on the link or copy and paste. NetAlly LRAT-2000 Link Runner AT Copper and Fiber Ethernet Network Tester |
| Question: | Does it light the port if connected to a switch |
| Answer: | Actually yes, it will blink the port on the hub/switch........ |
| Question: | Will this tester, test reverse connections |
| Answer: | It does...it detects shorts...opens... reversals...miswires...and split pairs |
Product features
RJ45 Tester, Continuity Tester, Coax Tester, LAN Scout Jr. Continuity Tester
This easy-to-use, compact tester saves time and money on the job. The LAN Scout Jr. tests continuity on twisted pair data wiring connections.
TRENDnet Network Cable Tester, Tests Ethernet/USB & BNC Cables, Accurately Test Pin Configurations up to 300M (984 ft), TC-NT2
TRENDnet
Product description
TRENDnet’s Network Cable Tester, model TC-NT2, is a comprehensive cable tester for network professionals. It accurately checks pin configurations for Ethernet cables, USB cables, BNC cables, and patch panel ports. The TC-NT2 identifies proper, severed, short circuit, and cross connected pins for cable distances of up to 300 meters (984 ft.). All components fit into a handy travel case.
PACKAGE CONTENTS
• TC-NT2
• Quick Installation Guide
• 2x RJ-45-to-BNC adapter
• Network patch cable
• Carry pouch
- ACCURATELY CHECK CABLES & PORTS: The comprehensive cable tester for network professionals allows you to accurately check pin configurations for Ethernet cables, USB cables (with TC-NTUF sold separately), BNC cables, and patch panel ports.
- CABLE TESTING DISTANCE: Tests over cables lengths of up to 300 meters (984 ft.)
- PIN TESTING: The network cable testers identifies proper, severed, short circuit, and cross connected pins.
- LOCAL & REMOTE TESTING: A transmitter unit facilitates loop testing and a receiver unit allows for cable testing in locations away from the transmitter unit
- TRANSMITTER INTERFACE: 2 x test ports, Manual test button, Auto test button, Power/tone switch, LED indicators.
- RECEIVER INTERFACE: Test port, LED indicators
- CONTINUOUS SCAN: Continuous scan mode is design to accommodate testing with cable ends in different locations
User questions & answers
| Question: | Will this test usb 3 cables? what kind of usb connectors are supported |
| Answer: | Hi Rich!,Thanks for your interest in TRENDnet! This cable tester won't be able to test USB 3.0 cables. You will want to look at TRENDnet's TC-NT3.Hope this helps! If you have any more questions, you can always respond directly to this thread or you can reach out to our 24/7 toll free tech support line at 866-845-3673 and someone will be happy to try and help answer any additional questions you may have!Have a great day!Thanks.TRENDnet Direct CS |
| Question: | Do you need to get the probe to do toning |
| Answer: | The probe is very helpful and I highly recommend that you get one in order to quickly locate cables, and prevent plugging your Trendnet into a cable that is under electrical load. But in the strictest sense of the word it is possible to tone without one. It doesn't even have to be Trendnet probe, but there is so much to be gained by using a probe, I hope you will consider my suggestion. |
| Question: | Is this product made in the USA |
| Answer: | Taiwan |
| Question: | Will this work for testing an ethernet cable where one end is the in-wall jack and the other end is a RJ-45 connector |
| Answer: | If you look closely at the pictures (or pictures of other testers that include multiple views) you'll see that the two units have female RJ45/RJ1X ports.So:-- If you're testing a single cable, you just plug each end of the cable into each unit.-- If you want to test, as you're asking, a cable with an RJ45 on one end and a wall jack on the other, you'll need a small patch cable to connect the wall jack to one of the units.-- If you want to test from wall jack to wall jack you'll need *two* short patch cables.If you look at the reviews/customer images for this unit, you'll see a (single) small patch cable *is* included. You can also just search Amazon for "6 inch ethernet patch cable" and you'll get a crap-ton of results to choose from. |
Product features
Local and Remote Testing
A transmitter unit facilitates loop testing and a receiver unit allows for cable testing in locations away from the transmitter unit
Continuous Scan
Continuous scan mode is design to accommodate testing with cable ends in different locations
Manual Scan
Manual scan is well suited for loop back cable testing
Cables and Ports
Accurately check pin configurations for Ethernet cables, USB cables (with TC-NTUF sold separately), BNC cables, and patch panel ports
Network Cable Tester, AT226-C NF-8601W LAN Ethernet Cable Tester RJ45 UTP STP Diagnose Tone Tracer for RJ45, RJ11, BNC, PING/POE 8 Identifier Telephone Wire Tracker
Product description
Functions
1. Capable to test open, short, cross connection
2. Perform crosstalk test on network cable to solve the potential problem of slow speed.
3. Quickly find the targeted cable without stripping isolation among unknown cables.
4. Measure length of network cable, coaxial cable, telephone cable.
5. TF function to import and export data.
6. Locate breakage and short position accurately.
7. Detect PoE presence.
8. PING Testing
9. Detecting voltage (90-1000V)
10. 8 remote indentifier are included.
Benefits
1. Big LCD color screen 320*240
2. Function of storage and memory
3. Currency detection and lighting lamp
4.Automatic delay power on-off
5.Low voltge alarm function
Item Specifics
Is_customized: Yes
Model Number: NF-8601W
Place of Origin: China
Port: RJ45, RJ11, BNC
Test length: RJ11,RJ45 ,BNC
Tracking Type: RJ45, RJ11, BNC , and Metal Cable
Other Function: PING test， PoE detect
Power: Lithium battery
Accessories Included
Built-in Lithium battery x 2 sets
telephone line adapter x 1 set
network cable adapter x 1 set
Cable clips x 1 set
- 【 PoE Function】 Identify which pins are providing power and detect how much voltage.
- 【 PING Function】To test network performance, data packet, min & max time.
- 【 AC Filter 】Tone trace cable with complete AC Interference Rejection.
- 【 Hub Blink 】Hub blink for locating network port by the flashing port light on Hub / Switch.
- 【 TF Function】 To import and export data from comupter (160 sets, txt format).
User questions & answers
| Question: | Can this unit speed test a cable? 100mbs? 1000mbs |
| Answer: | Hi,network cable tester AT278 can not speed test a cable on 100mbs or 1000mbs. |
| Question: | Does this test for cable signal? like 100 or 1000 mbit |
| Answer: | I think so, but I'm not 100% on that. I use mine mostly to check for fault types, and distance from end to fault location. You should read the spec and data sheets to see if that is listed. |
| Question: | Will this work with tracing cables that are in a POE switch without burning out the tester |
| Answer: | Manual does not recommend using this with POE |
| Question: | Does this measure distance to short or open |
| Answer: | Yes, it can measure distance to short and open. |
Zoostliss Network Cable Tester RJ45 RJ11 RJ12 UTP LAN Cable Tester Networking Tool
PF
Product description
Features:
Following are abnormal connections:
If one cable, for example cable NO.3 is open circuited, the two NO.3 lights of the main tester and remote tester will not turn on.
If several cables are not connected, several lights will not turn on respectively. If less than two cables are connected, none of the lights is on.
If two ends of a cable is disordered, for example NO. 2and NO. 4, then displays on:
Main tester: 1-2-3-4-5-6-7-8-G
Remote tester: 1-4-3-2-5-6-7-8-G
If two cables are short circuited, neither of the corresponding lights is on of the remote tester while main tester remains unchanged. If three cables, including three, are short circuited, none of the corresponding lights is on.
If test patch panels or wall plate outlles, two cables which can match each other (RJ45) will be connected to the tester.
If test cables of the same axes, BNC turns on when the cable works.
9V reduplicated battery is used in this tester. Battery is advised to change if any weak light appears.( Battery is not included.)
Color: white
Main tester
Size: 105*67*28mm
Weight: 74g
Remote tester
Size: 105*38*28mm
Weight: 47
- Keep your network running smoothly by testing your cables to uncover problematic shorts, open wires, crossing pairs and other wiring mishaps
- Use for testing your homemade Ethernet patch cables to make sure they are in working order prior to connecting to your devices
- Tests RJ45 cables, RJ11 telephone cables and network cables. Requires one 9-volt battery (not included)
- Easy to read LED display indicates problems.Hand-held for portability.
- If you do not like our products, we accept 30 days return and 60 days replacement, please feel free to contact us if you face any problems
User questions & answers
| Question: | does it comes with a case/pouch |
| Answer: | It is SUPPOSED to. The first one sent to me was used, broken, no instructions and no pouch. It was returned and I got a new one that had a small zippered pouch. |
| Question: | Is there a maximum length of cable this will work on |
| Answer: | I’ve tested with 200ft+ cable runs and it works great. Frankly it’s the quality/version of cable run and environmental factors that matter more than the test tool. If the tool can’t get its signal to the test point, neither will your gear. They’re bound by the same constraints. |
| Question: | Does this work with cat 6 cable? i purchased one and i can't get it to light all 8 for cat 6, even when i visually verify that the pin-out is correct |
| Answer: | Yes, it does work with Cat 6 cable. I checked over 30 runs from our patch panel to outlets in our office, some over 300 feet away, and it works perfectly. If you take a one or two foot patch cable, you should get all 8 wires to light the LED's in sequence. |
| Question: | does this test each line individually & sequentially? I have rj45 preinstalled in wall, i am trying to determine if there are crossed or open lines |
| Answer: | It steps through each wire and tests each one. If any of them don't work you'll see the light not light up. For example: It lights up 1-2-3-4-5-6-7-8 in order.... If 5 is open you'll see it skip 5 and go to 6. When I mis-crimped some wires it caught this and I re did them. |
Network Cable Tester - NOYAFA Cable Wire Fault Finder for RJ45 Cat5, Cat6, 5e, 6e Measure Length, Locate the Breakage Point, Check Wiring Error with 8 Far-end Passive Test Jacks
SHGROUP
Product description
Type of Tester Cable
STP/UTP twin twisted cable, coaxial cable, telephone line
Tester Port
Tester RJ45 master port (M), tester LOOPBACK RJ45 port (L), far-end recognizer RJ45 port (R)
(BNC and RJ11 converters (not included in the set), can be used to measure and check the continuity of coaxial cable and telephone line)
Length Measurement of Twin Twisted Cable
Scope: 1 to 350M (3 to 1,200 FT) calibration
Calibration accuracy
3% (0.5m or 1.5 ft) (calibrating cable > 5 M)
Shipment accuracy
5% (0.5m or 1.5 ft) (AMP, AT&T Class 5 cable)
Unit of Measurement
Display in meter (M) or feet (FT)
Length Calibration
User can set self-calibration factor by a given length cable.
The length of calibrating cable is more than 5M
Wire Sequence and Locating Cable Error
Check errors such as open circuit, short circuit, reverse connection, cross- over or cross-talk interference
Locating Cable
Included 8 far-end passive test jack
Automatic Time
Delay Shut Off Time; The tester is idle for 30 minutes
Powered by
4*1.5V AAA batteries (not included)
Working Ambient Temperature
-10℃ to 60℃
Size
8.2*18*3.8cm / 3.2*7.1*1.5“
Net Weight
0.21kg / 7.4oz
Product contain
1*Multi-Network Cable Tester
8*Far-End Test Jack
1*Instruction Manual
- ★【 LOCATES THE WIRING OR CONNECTION ERROR 】: Measures cable length and determine the distance of open circuit and short circuit.Permits you to check wiring error in 5E/6E twisted cord network, coaxial cable and telephone line.
- ★【 HIGH QUALITY & ONE YEAR WARRANTY 】: Auto time delay shut off.Comes with 8 far-end passive test jack.Far-end recognizer with prompt voice.Single board computer software watchdog design and reliable operation.
- ★【 LIGHTWEIGHT & EASY TO CARRY 】: Self-checking function and automatically compensates any change in battery capacity or ambient temperature.Simple and easy to use, big LCD screen to display test results. Compact, lightweight, easy to carry and use.
- ★【 LONG BATTERY LIFE 】: Applicable for open circuit, short circuit, jumper wire, reverse connection or cross-talk interference.Dynamically calibrates cable length and make length measurement as accurate as 97%. Portable unit with long battery life (wait-case or standby mode for over 50 hours).
- ★【 EASY TO USE 】: Efficient, effective, reliable. A person is enough to complete cable continuity check and cable sequence.Indicates pair integrity of the cable. Measure length and pair with or without far-end recognizer.
User questions & answers
| Question: | Will this test the shield on shielded cable |
| Answer: | Yes, it tests shielded cable. My project include testing both types of cables. |
| Question: | Is this a good product are they reliable |
| Answer: | This product is phenomenal. One of the best features of this product is that it will communicate over any two conductors whether the cable has been wired properly or not. It will find the remote identify the remote and then diagnose the pin out of both connectors |
| Question: | The device has an unexplained display mode where it shows all pairs connected, but it flashes multiple pairs on the display. What is the meaning |
| Answer: | I think it is crosstalk(bleedover) on a short cable. I havn't noticed it on 4 ft or longer cables. |
| Question: | What types of network cable tests are supported |
| Answer: | I have personally tested cat5, cat5e, Cat6, and cat7. I would have to imagine it works with anything 8pin w/ rj45 end. |
Latest Reviews
View all
Estee Lauder Eye Anti Agings
- Updated: 18.02.2023
- Read reviews
Occult Books
- Updated: 10.03.2023
- Read reviews
Ao Smith Electric Heaters
- Updated: 09.05.2023
- Read reviews
Alex Toys Gifts For Year Old Boys
- Updated: 16.05.2023
- Read reviews
Rated Cpu Coolers
- Updated: 19.02.2023
- Read reviews
