Product description

VesselView Mobile 8M0157078 is compatible with all Mercury outboards or MerCruiser stern drives with SmartCraft systems. Monitor your engine's performance through your mobile device. It uses common Bluetooth technology. It is quick and easy to pair. The information provided via VesselView Mobile is much more accurate than most analog gauges. You’ll have a much better sense of your true rpms, your fuel burn, your speed, your fluid pressure levels – anything that can be measured on analog gauges will be more accurate with VesselView Mobile. Installation may require additional parts, connections or wiring depending on boat rigging. Mercury Marine’s passion for performance is matched by your drive for the new, the unknown. Our legendary reliability and durability let you boldly embrace your next adventure—large or small—knowing you’re backed by the best quality design, engineering, and materials.

• DIGITAL GAUGES ON YOUR PHONE OR TABLET - Keep track of your fuel usage, engine temperature, battery charge, RPM - or any other data points you want to see.
• PLUG-N-PLAY SETUP - Install in just a few minutes on any Mercury SmartCraft-capable engine: outboards and sterndrives, 2004 and newer, 40hp and up.
• CONNECTS WITH UP TO FOUR ENGINES - VesselView Mobile displays key data for up to four engines on your iOS or Android smartphone or tablet.
• KNOW WHAT'S GOING ON - Accurately monitor true engine running hours and know ahead of time when an engine is due for a regular maintenance interval.
• GO BOLDLY - Enjoy more time on the water with the peace of mind that VesselView Mobile is monitoring the engine using Bluetooth Low Energy technology.

User questions & answers

Question:	Will this work with my 2014 115 hp 4 stroke
Answer:	Yes. It simply just plugs in.
Question:	Does it give you gallons per hour data
Answer:	As far as fuel data it will give you gallons per hour, miles per gallon, distance to empty and time to empty (changes depending on how fast you are moving). It is also helpful as you can enter your vessel fuel capacity and how much fuel you are starting with, and as the engine burns it the app will deduct it so you know exactly what is remaining.
Question:	Have a 2011 350 mag will it work and does it give codes for alarms and sensors causing them
Answer:	It will work on your engine and it will tell you what alarm is on like ( high oil temperature, shift alarm , overheating , low water pressure etc.) then its a technician work to find out why is causing the alarm to come on.
Question:	Will this work on a 2016 Verado
Answer:	from what I have read it works on all Mercury 40HP & above from 2012 up Super product ! check with your dealer !

Product features

Know What's Going On.

Accurately monitor true engine running hours and know ahead of time when an engine is due for a regular maintenance interval.

Plug-N-Play Setup.

Install in just a few minutes on any Mercury SmartCraft-capable engine: outboards and stern drives, 2004 and newer, 40hp and up.

Go Boldly.

Enjoy more time on the water with the peace of mind that VesselView Mobile is monitoring the engine using Bluetooth Low Energy technology.

Digital Gauges on Your Phone.

The VesselView Mobile app displays key data for one to four engines on your smartphone. Keep track of your fuel usage, engine temperature, battery charge, rpm – or any other data points you want to see. There are dozens of data points to choose from, and you can customize up to three screens to fit your style. You’ll have a better sense of your true rpm, your fuel burn, your speed, your engine temperatures and pressures – anything that can be measured on analog gauges will be more accurate with VesselView Mobile.

Easy to Install and Set Up.

The VesselView Mobile module connects to any Mercury SmartCraft-capable engine – outboards and sterndrives, 2004 and newer, 40hp and up. Install the module in just a few minutes, connect with the app and you’re ready to get on the water. You can select your preferred Mercury Dealer in the app and share your engine data with them for quick troubleshooting. An optional Mini Mount System holds your phone on a secure surface for easy access to data and safe boating.

Know What’s Going On.

With the VesselView Mobile module connected to your engine you can keep track of true engine running hours and know ahead of time when you’re due for a regular maintenance interval. In addition to providing information on your engine’s performance, VesselView Mobile can even notify you if something isn’t right. More than just a series of beeps or a numeric code, VesselView Mobile will tell you in clear language what is going on with your engine.

Dealers, Shops & More.

When you select your Preferred Dealer within the app, you can share your engine data with your dealer, who can then review any alerts and help you keep your engine in top condition. The VesselView Mobile app also has a map feature that includes local points of interest such as marinas, restaurants, or local bait shops – so you don’t need to switch between apps or search manually for them. It also comes with handy checklists, so you don’t forget any important items on shore.

Outboards

• 30-40 hp (3cyl) EFI FourStroke - 0T409000 and above
• 40-60 hp (4cyl) EFI FourStroke - All
• 75-115 hp EFI FourStroke (1.7L) - 1B366823 and above
• 75-115 hp EFI FourStroke (2.1L) - All
• 75-125 hp Optimax - All
• 150 hp FourStroke - All
• V6 Optimax - 0T178500 and above
• V6 EFI TwoStroke - 0T409000 and above
• V6/V8 FourStrokes and Verado - 2B527482 and above
• L4 & L6 Verado - All

Sterndrives

• 3.0L MPI - All
• 4.3L MPI - All
• 5.0L/350 MAG/5.7L/377 MAG/6.2L MPI - 0M300000 and above
• 200–250 hp (4.5L) and 300–370 hp (6.2L) - All
• 496/8.1L - All
• 8.2L - All

Inboards (Gas)

• 5.0L/5.7L/6.2L MPI - GM engines - 0M300000 and above
• 4.5L/6.2L - Mercury engines 2A441953 and above
• 8.2L - All

Product description

Pyle Model : PLCM7500

Rearview Camera & Monitor System

Backup Rearview Camera & Monitor Parking/Reverse Assist System, Waterproof, Night Vision, 7'' Display, Distance Scale Lines, Swivel Angle Adjustable Cam

System Features:

Backup Camera & Monitor System

Distance Scale Line Display

Includes All Necessary Cables & Wiring

Monitor

7'' TFT / LCD Mirror Monitor Screen Display

16:9 Wide Screen

Video System: PAL/NTSC

Dual (RCA) Video Input Connector Jacks

Ability to Connect An Additional Camera Source

Includes Universal Windshield Mount Holder

Power Supply: DC 12V

Dimensions: 7.60''W x 5.24''H x 0.98''D

Camera

License Plate Mount Camera

Rugged & Durable Exterior Mount

Slim-Bar Style Housing

Swivel Angle Adjustable Cam

Marine Grade Waterproof Construction

IP-67 Water Resistant, Fog Resistant

True Color Reproduction

Total Pixels: 656 x 492

Night Vision Ability

Low Lux Light Performance, 0.2 Lux

Wide Viewing Angle: 170 Degrees

Black Zinc Aluminum Die Cast Chrome

17 Foot Male to Male RCA Video Connection Cable

Power Supply: DC 12V

Dimensions: 10''W x 1.3''H x 1.26''D

Add an extra line of safety and become a better driver with this backup camera and monitor system. The Pyle PLCM7500 allows you to mount your camera and monitor exactly where you need them. The small and durable camera installs easy and provides you with an extra set of eyes when on the road. Steer clear of bicyclists, watch out for pedestrians and skill your way into those tight parking spots like never before. The 7'' LCD display monitor and housing includes a windshield mount holder for ideal placement. It adds crisp color picture from your backup camera and reveals a picture display when you reverse or when visibility is limited. The slim bar-style waterproof camera is rugged and the preferred mounting location is just above the rear license plate. The system comes with all the necessary cables and wiring for connection. Drive safer and smarter with the Pyle PLCM7500 Backup Camera and Monitor System.

• BACKUP CAMERA: A rugged backup rear view camera with true color reproduction at 656x492px. Has a low lux performance and wide viewing angle at 170°. This wired cam also has an adjustable swivel angle
• WIDESCREEN MONITOR: A backup camera system with HD 7 inches TFT/LCD mirror monitor display, 16:9 widescreen ratio. Video system is PAL/NTSC. Has an ability to connect to camera source with dual RCA jacks
• DASHBOARD MOUNTABLE: Both car backup camera and backup camera monitor are mountable. The car rear view camera can be mounted to license plate with its slim bar style housing
• WATERPROOF & NIGHT VISION: This backup camera is IP-67 marine grade waterproof to combat bad weather. It's also fog resistant with a night vision ability. Kit includes a small wireless remote
• DISTANCE SCALE LINES: A backup camera kit that features an accurate distance scale line display for proper parking and reversing without relying on side mirrors alone

User questions & answers

Question:	does it beep when aproaching an object
Answer:	No it does not,but a great camera....
Question:	is this system wireless
Answer:	No it's not wireless, I chose this one because sometimes you get interference with the wireless ones. I had the smaller 4" wireless one first from another manufacture and it was hard to see and did cycle on and off every once and awhile. If your young with good eye sight you might like a smaller unit, this one is big but I like it better than the small one. Hope this helps
Question:	what is actual size of monitor
Answer:	According to what now is posted on their site, the monitor's physical dimensions are 7.60''W x 5.24''H x 0.98''D
Question:	Does the screen only come on when you are backing up
Answer:	The screen comes on when the red wire is connected to 12v and the black wire is connected to ground. In this scenario, with the screen powered on and nothing connected all you will get is a blue screen but connect the included camera to the video input on the screen and supply 12v to the camera and the blue screen will disappear and be replaced with the video from the camera. Power both camera and screen from the same source and they will turn on and off together (this way you will never get a blue screen). Connect them to the vehicle's backup lights and they both will turn on when the vehicle is in reverse. I drive a cargo van and have mine connected so that it is on as long as my engine is running, that way I can see behind me while I am driving.

Product features

Backup Rearview Camera & Monitor

Add an extra line of safety and become a better driver with this backup camera and monitor system. The Pyle PLCM7500 allows you to mount your camera and monitor exactly where you need them. The small and durable camera installs easy and provides you with an extra set of eyes when on the road. Steer clear of bicyclists, watch out for pedestrians and skill your way into those tight parking spots like never before. The 7'' LCD display monitor and housing includes a windshield mount holder for ideal placement. It adds crisp color picture from your backup camera and reveals a picture display when you reverse or when visibility is limited. The slim bar-style waterproof camera is rugged and the preferred mounting location is just above the rear license plate. The system comes with all the necessary cables and wiring for connection. Drive safer and smarter with the Pyle PLCM7500 Backup Camera and Monitor System.

Pyle’s - PLCM7500

The latest Backup Camera and Monitoring System Kit is something to check up on. The kit includes a waterproof camera, a widescreen monitor, remote and more. These are all perfect and very helpful for all drivers. It even has a night vision and fog resistant feature for a safer and secure drive.

BACKUP CAMERA

A rugged backup rear view camera with true color reproduction at 656x492px. Has a low lux performance and wide viewing angle at 170°. This wired cam also has an adjustable swivel angle.

WATERPROOF & NIGHT VISION

This backup camera is IP-67 marine grade waterproof to combat bad weather. It's also fog resistant with a night vision ability. Kit includes a small wireless remote.

WIDESCREEN MONITOR

A backup camera system with HD 7" TFT/LCD mirror monitor display, 16:9 widescreen ratio. Video system is PAL/NTSC. Has an ability to connect to camera source with dual RCA jacks.

DASHBOARD MOUNTABLE

Both car backup camera and backup camera monitor are mountable. The car rear view camera can be mounted to license plate with its slim bar style housing.

DISTANCE SCALE LINES

A backup camera kit that features an accurate distance scale line display for proper parking and reversing without relying on side mirrors alone.

• 1.9 in 1 Measuring Type/Range:Voltage 0-200V,Current 0-100A,Power 0-20000W,Impedance 0-1000Ω,Internal Resistance 0-999mΩ,Capacity 0-1000AH,Dump energy 0～9999kWh,Running time 0-999 hour.
• 2.LCD Display:Large-screen LCD with a full sight of 180° view,The blue backlight can be turned on/off manually.
• 3.Two modes: normal display mode and dormant mode.
• 4.No screws design:Push-on terminal,no need to connect with a screw.
• 5.Wildly application:DC multifunction battery meter wildly applied to solar system/industrial assembly line/Automobile/RV etc.

User questions & answers

Question:	What is the longest wire you can run from the shunt to the meter
Answer:	I used a 22 ga. cat 5 wire from the shunt to the meter approx 30 feet and had no problems.
Question:	Is there a wall mount plate this will fit into
Answer:	The unit incorporates a thin bezel meant to be a finished flush-mount surface. Plastic spring clips on the sides hold it in place if you cut out the correct sized rectangular hole. I mounted it in 1/8" plywood. Note that control wires go into the side of the unit, so mounting in something thick, like 1/2" plywood, would require some clever cuts to let the wires pass through.
Question:	Is this meter capable of measuring mah or ah capacity of a 14.4v-50v battery pack
Answer:	Yes,the meter can measure mah or ah capacity of a 14.4v-50v battery pack.
Question:	Why please has the shunt got a big saw cut in it
Answer:	I believe that is part of the calibration process in the factory. They nibble away at the shunt metal until the resistance is correct for the designed shunt maximum current.

Product features

Multifunction Battery

The PZEM-015 DC multifunction battery is mainly used to test all kinds of battery’s voltage, discharge current, discharge power, discharge impedance, internal resistance, capacity, dump energy, energy consumption and running time, and display the measurement data through LCD screen.

Specification

Power consumption

Normal working state: 0.03-1.2 W

Sleeping state: 0.5mW-0.5W

Working temperature-20’C ~ +60’C.

Display interface is large-screen LCD, it can display eight parameters at the same time.

1. Power: Measuring range: 0-20000W, Starting measure power: 0.2W
2. Impedance: Measuring range: 0-1000Ω
3. Voltage: Measuring range: 0-200V. (when the test voltage is ＜8V, please use the independent power supply mode)
4. Current: Measuring range: 0-100A. The starting test current: 20mA
5. Internal resistance:Measuring range: 0-999mΩ
6. Capacity: Measuring range: 0-1000AH
7. dump energy：Dump energy is display via the battery symbol, totally 10 grids, every grid present 10% energy.
8. accumulate energy consumption:1 Measuring range: 0～9999kWh. Note: 1Wh=0.001kWh=0.001 Kilowatt
9. Running time:Measuring range: 0 ~ 999 hour (without load the time will not accumulate)

No screws design

• Push-on terminal, no need screws to connect.

Wildly application

• DC multifunction battery meter wildly used for solar system/ industrial assembly line / Auromobile Etc.

LCD Display

• Large-screen
• LCD with all sight 180° view
• The blue backlight can be turened on/off manually

Product description

Specifics



HD Monitor:

Screen Size: 7 inch

Chip: AHD 1080P image processor

Resolution: 1024*600 IPS

Input Signal: AHD720P/960P/1080P, CVBS singal

TV System: PAL/NTSC auto

Screen ratio 16:9

Material: Metal/ABS

Rear-view: AV2 AUTO reverse when trigger activated

View Angle: up / down / left / right

Operate mode: key operation & remote control

Operating voltage: DC12V-36V

Power consumption: about 6W

Memory Size: Support 256G SD card at max.



Rear View Camera:

Image Sensor: AHD

Image Sensor: 2053 chip

Resolution: 1080P

Waterproof Level: IP68

Power Supply: 12-36V DC.

Lens Viewing Angle: 170 Degrees

Work Temp: -20℃~+60℃

Night Vision: Supported, color pictures at night



Package List:

1 x HD Car Monitor

2 x Front/Rear/Side View Camera

1 x 5meter (16ft) AV Cable

1 x 15meter (49ft) Cable

1 x Power&Video Cord

1 x Remote Control

1 x Standing Bracket

1 x Manual Book

1 x Sun visor

2 x Screws

• Built-in DVR: great recording function, it supports record 2 channels camera at the same time and loop recording via SD card up to 256GB maximum SD card(Not Included)
• 7 Inch 2 Split Monitor：with 1080P image processor. It supports 2 video inputs that allow several viewing modes - single full view, split dual view, by pressing V1/V2 button to switch
• Dual Rear-view Camera: IP68 waterproof, colorful night vision, 170°wide view angle. Whole image rotation, Mirror view/normal view, with/without distance guide line are available to set in menu
• Backup Trigger Function: After connected blue trigger cable to reverse light positive, when you pull reverse gear, the monitor will display CH2 automatically, offering parking assistance
• Designed Specially for: RV/Truck/Bus/Camper etc. Wide voltage power input:12-36V DC Power.

User questions & answers

Question:	What is the Resolution of the Camera
Answer:	It is an upgraded 1024x 600 and the image of the monitor has indeed been improved.
Question:	Can I adjust the camera up and down or is there only one position
Answer:	Hi. You can adjust the camera to adjust to the position you want. The camera stand is movable.
Question:	Do both cameras record to the DVR at the same time
Answer:	Yes, this backup camera system support both cameras record to the DVR at the same time
Question:	Hi,does the DVR record both camera or just the front camera
Answer:	Hi, both camera are rear view camera. The DVR would record videos from both camera.

Product description

The PinPoint ORP Monitor will measure the ORP (oxidation-reduction potential, or REDOX) of your system. It is popular with those who use ozone gas or potassium permanganate as an artificial oxidation agent in fresh or saltwater. Constant monitoring of the ORP is useful in keeping tabs on the overall health of a system, as a drop in ORP often precedes visual or other indications of trouble. Many serious marine enthusiasts who do not use ozone gas use this meter to judge the overall health of their reef systems. This unit features a 1mV digital resolution and a platinum electrode. The range is ?2000 to +2000 mV.

User questions & answers

Question:	does this come with ac adapter
Answer:	HolaNo, el equipo trabaja solo con baterías.saludos.
Question:	Does this come with a carrying case
Answer:	No
Question:	i seen opposing answers to if this is an out the box complete testing, one said it came with 2 probes and you have to buy more?others said the opposit
Answer:	Includes 1 probe. No others to buy
Question:	Can I swap other probes such as pH, temperature, oxygen or other probe attachments to this monitor, if where can I purchase
Answer:	Sorry, I have never tried to use it for anything other than what it was intended to do, however, I suspect the digital display would not accommodate other probes accuracy.

Product description

The American Marine Pinpoint pH Monitor is an affordable unit featuring .01 resolution. The Pinpoint pH Monitor is sold complete with probe and calibration fluids (9 volt battery not included).

User questions & answers

Question:	want to know if it works for freshwater and marines aquariums
Answer:	It works in my marine aquarium just fine.
Question:	Does this package include a suction cup for mounting in the aquarium
Answer:	Didn't get one with mine. Also it broke not long after I got it.
Question:	how much calibration fluid comes with the probe? (i plan to store this out of a tank and thus will need to calibrate regulary, I expect
Answer:	Hi, They include 1 packet of high and 1 packet of low calibration fluid. So basically enough for one calibration. If you don't plan on keeping the probe in your tank all the time, be sure to use Electrode probe storage fluid. The tip of the probe should always remain wet. For short period of time you can use calibration fluid in a little bottle to store the probe but if you are going to store for extended times i would recommend storage fluid.
Question:	Hello could I test saliva with this
Answer:	Yes you could, but you would need quite a large sample of saliva to use the probe. It would probably be better to use litmus paper.

• Applicable Battery Type --- DROK digital battery monitor is suitable for 10-100V (12v 24v 36v 48v 60v ) lithium battery, lead-acid battery, lithium iron phosphate battery, Ni MH battery.
• Application --- Can be used as battery voltage meter, battery capacity tester and temperature indicator panel for car, marine, RV, boat, etc.
• Temp Gauge in F. --- The temperature indicator can display in Fahrenheit.
• The One You Want --- Easy to install and use. Allows you to program the percentage with a corresponding voltage.
• Default --- 48 volt lead acid battery.

User questions & answers

Question:	How do I change default to 36 volt
Answer:	Dear customer, You can program battery specification on menu ”1---” or menu "3---". For more details, please refer to our manual. Any more questions, please feel free to contact us. Best regards, DROK
Question:	Can i use this device on an agm battery? i have a 2005 prius
Answer:	Yes. AGM is lead/acid
Question:	How does it determine battery state? By voltage level or setting a parameter? If it's a parameter, what's the highest setting. I'm @2000+ a/hrs
Answer:	Voltage level and temperature
Question:	The description says fahrenheit in one place and Celsius in another place. Which is correct
Answer:	Dear customer, You can change temperature unit on this item. Fahrenheit or Celsius is available. Best regards, DROK

Product features

Multi-functional Meter

Our batter meter is fully functional type, not only can display battery capacity and voltage, but also can display the Fahrenheit or Celsius temperature, two kinds of modes could be easily switched.

Switch ON/OFF

Still wondering the old type of battery meter that without on/off switch? The old type of battery meter cannot be turned off unless cut off the wiring connection.

Our battery monitor meter is designed with the turn on/off switch, convenient for your daily using.

Back Cover & Removable Wire Terminal

It is built with well made back cover to protect the battery from damaging and dust.

Removal wiring terminal, convenient for your installation and store.

Panel Dimension

Product description

Boat Command - Monitor from your phone, tablet, computer - GPS Tracking - Monitor bilge activity remotely - Monitor shore power remotely - For Yachts, Fishing Boats, Sailboats, Powerboats, - Monitor battery level, shorepower, high water, bilge aclitivity, security, more - Complete marine telematics - Remote control capable

• GPS Tracking / anchor alert
• Easily monitor bilge activity and shore power
• Observe inside temperature for pets, etc.
• Set high water alert
• Receive text and email alerts

User questions & answers

Question:	Is there a way to connect this to a battery temporarily (72 hours)? Having to leave the boat at a marina and won't have time to install properly
Answer:	Yep just connect the leads to the battery
Question:	This is a great product. the app to control it has disappeared from the ios app store months ago. where is the app and how to install on new phones
Answer:	I would contact the developers. They are very helpful.
Question:	Does this monitor the temperature inside the boat? i’m a liveaboard- i have a dog and i want to make sure it doesn’t get too hot, or be alerted if the
Answer:	There is a temperature probe that is an option for the boat command unit that can monitor inside temperature. I think the list price for the sensor is around 30 bucks There are also optional control relays you could use to turn on AC or ventilation
Question:	Does this connect to a cell signal or does it use wifi to notify me
Answer:	Boat Command connects to a GSM network which is one of the global cell phone networks. I do not have WiFI on my boat and I receive e-mails and text alerts from Boat Command and can access all of my boat’s vitals from any where in the world. I have tried this all over Asia, Europe and the U.S. in fact I have it send messages to both my Italian mobile number and my U.S. mobile number, with no problems. Of course you have to pay a monthly fee for this service. There are several packages offered depending upon how frequent you want updates. If I recall correctly, I took a middle of the road package and I pay $135 annually ($11.25/month). I hope this helps.

Product description

Specifications: Weight: 21g  Voltage Range: 5-15V  Power Input: DC 12V-24V Portiforium Dimension: 3cm (1.18in) Product Dimension: 3.7cm x 2.9cm (1.46in x 1.146in) Protection: Reverse Connection Protection. Materail: High Temperature Resistant Nylon Flame Retardant Materials Package included:  2 x Blue Connector Cap 1 x Waterproof LED DC Digital Display Voltmeter

• Widely Compability:Universal compatible with 12V Motorbike Car / Boat / ATV / UTV / Camper / Caravans / Travel Trailer etc.
• LED Flash :Help monitor the storage-battery voltage, LED will alarm flash if the voltage is higher than 15V.
• 15V Voltage Range:11.3V-11.9V RED Led indicate the battery should be change, 12.0V-12.5V YELLOW Led indicate normal when the car engine is OFF, 12.6V-15V GREEN Led indicate normal when the engine is ON.
• Safe&Heathy Material:High Grade Flame Retardant Materials,IP65 Waterproof, CE and Rohs Certify, Totally Environment Friendly.
• Product Dimensions: 3.7cm x 2.9cm (1.46in x 1.146in), Portiforium Dimension: 3cm (1.18in).

User questions & answers

Question:	will this work with a deep cycle battery for a trolling motor
Answer:	Yes, should work well. Mine seems to be accurate when using Trolling motor.
Question:	Does this show how low the battery voltage drops when starting or do you just have to watch the gauge
Answer:	It adjusted according to your vehicle
Question:	Can I put on a fuse amp on this a 10 or 15 a fuse amp and puce to the battery
Answer:	Yes it should work with no problems.
Question:	Does this fit in the same hole in the dash has a cigarette lighter
Answer:	It is a little larger.

• 【High Resolution】Small Touchscreen Solutions - 12.1" 10 point Multi-Touch Optically Bonded Capacitive Touchscreen, HDMI/VGA/DVI/AV Video Input & HDMI Video Signal Output, Native Resolution 1280x800, Wide Viewing Angle IPS (In-Plane Switching) LCD Panel, 1000NIT, Contrast 1000: 1, Aspect Ratio 16x9.
• 【Compatibility】Small Touchscreen Solutions - The portable monitor can be connected to lots of devices with HDMI/VGA/DVI ports including computers, laptops, Mac, and is rugged for industrial integration and automation projects. It also works as CCTV Security and many systems.
• 【Capacitive Touch】Small Touchscreen Solutions - Connect it with your device via HDMI/VGA/DVI cable, then power the monitor via the included DC cable. The function of touchscreen functions when the monitor is connected with your computer/laptop/system via USB cable.
• 【VESA】Small Touchscreen Solutions - Slim and Lightweight monitor with a sleek and metallic finish. The 12.1" HDMI, VGA, DVI monitor can be wall mounted via 75mm×75mm VESA ports or settled on the desktop with the stand.

Product features

Truly Rugged 12.1 HDMI Monitor Features

• Sunlight Readable – Ready for all environments
• Waterproof/Dustproof– Built to Stringent IP67 Standards
• Bonded Glass – Optically Enhanced for clarity and viewability
• Multiple Inputs – HDMI, SDI, DVI, VGA, and AV Inputs
• HDMI Output
• Automatic Dimming – Built in Ambient Light Sensor
• Superior Image – Scalable resolution up to 1080P
• Extended Temperature Range

Truly Rugged 12.1 HDMI Monitor Compatibility

• Waterproof IP67 Tested
• Optically Bonded Tested Touchscreen
• Dust Proof
• Fog Proof
• Advanced Capacitive Touchscreen
• Perfect for Indoor our Outdoors
• FCC Certified
• CE Certified
• E13 Automotive Certified
• RoHs Compatible

HDMI Input & Output

The 12.1" touchscreen display monitor comes with an HDMI output that allows you to chain up a few 1219 series 12.1" touchscreen monitors or output to other HDMI monitors. With the included waterproof cables, the 1219GNH is IP67 on all sides and angles.

Package Contents

• 5M Waterpoof Power Lead with Optional AC Adaptor or Cigarette Lighter Car Adaptor
• 1.8M Waterproof 26PIN Multi-Input Video Cable
• 5M Waterpoof HDMI Cable
• 5M Waterproof USB Cable
• 1.8M Waterpoof Audio Cable

12.1" IP67 Sunlight Readable Optical Bonded Capacitive Touchscreen LCD Industrial Display Monitor with HDMI, DVI, VGA & AV Inputs

• Audio Input x 4 / Built-In Waterproof Speaker
• 1280x800 Native Resolution, 16x9 Aspect Ratio
• Chip Monolithic Ceramic Capacitors for Improved Durability
• High Performance Image and Video Signal Processor
• AISS - Advanced Image-Scaling and Shaping
• Auto Power-On upon signal detection
• Function to Disable Front Button(s) and On Screen Text
• VESA 75mm Mounting Holes

• ☂【We Are Different】Upgraded high-quality QC 3.0 USB outlet with Limited Time NEW PRODUCT experience price, worry-free 60-Day refund Guarantee, 5-Year Replacement Warranty and Lifetime Support Guarantee. Qidoe car chargers, your ideal choice.
• ☂【Convenient Switch】Designed with a high-quality easy to operate on/off power switch for energy-saving and devices protection, never need to worry about draining battery power.
• ☂【Faster than Fast】This Cigarette outlet is Designed with dual USB ports supporting QC 3.0, whose max single output is 18W. Built-in official Qualcomm smart chip, will intelligently detect your devices and simultaneously charging 2 devices at optimal current. Charge compatible devices up to 4 times faster than conventional charging, backward-compatible with QC 2.0 & 1.0.
• ☂【Voltage Display】This USB installation socket builts in digital LED voltage monitor, displays the real-time accurate voltage status of your vehicle's battery, for preventing problems caused by low voltage, the light also makes quick and easy to find USB ports in the dark or at night.
• ☂【Multiple Protection】Certified by CE & ROHS with Over-load, Over-current and Short Circuit Protection to ensure charging safety, meanwhile, built-in Smart IC ensures the circuit won't be burnt out if wrong wiring. IP66 waterproof grade, dose good job on marine, boat and Golf Cart.

User questions & answers

Question:	This looks like a modular design. is there a way to add another usb charger with the switch, i don't need a 12v socket
Answer:	Yes, you can. I did too but I had to buy a separate one to replace the 12v socket. They screw out very easy and the wiring isn't hard to figure out.
Question:	What's the recommended fuse amperage for this
Answer:	3 amp I believe
Question:	Just to clarify the switch only cuts off the USB port
Answer:	no, it cuts off the usb port AND the readout. why is everyone saying "depending on how you wire it" for all these questions? there is one way to wire it. PERIOD. a positive and negative terminal on the back. thats it. also, the readout is blue. not red. on mine anyway.
Question:	What size are the sockets and the gauge dimentions
Answer:	the holes for the gauges is 7/8 inch or 22mm, the panel face is 4 inches by 1 5/8 inches

Product features

Limited Time Offer

This is the latest version of 12v cigarette outlet with switch, we also provide value-for-money new experience offer and after-sales protection, the promotion deadline is This Sunday.

High Power Socket

Total power up to 120W (12V) / 150W (24V). Enough for everyday use, fits perfectly with compatible devices such as dashcam, GPS, vacuum cleaner, air purifier, etc.

Portable Build for Space-Saving

Benefit from a lightweight and compact construction, that’s smaller than most Quick Charge 3.0 USB chargers on the market after installation.

Easy Installation

This usb socket outlet fits most vehicles dash panel and rocker switch panel, very easy to be installed within 25 minutes, just connect “+” to battery positive pole, “-” to negative pole.

LIFETIME PROMISE

We promise Qidoe Products are OFFERED REFUND or a REPLACEMENT if you are not satisfied with the product.

Package Include

1 * QC 3.0 USB Charger & Outlet

2 * Connect wires

4 * Fixing Screw

Specification

Rating Voltage: 12-24V

USB Output: DC 3.5-6.5V/3A, 6.5-9V/2A, 9-12V/1.5A

Material: Copper + ABS Plastic

Operating Temperature: -40 to 70℃

Multi-purposes: supply power for cellphone, tablet, GPS and other USB-devices

Smart IC Technology: Outputs stable current without fluctuation

Product description

Faria's Coral-series provides a great look to your boat's gauge panel. Each Coral gauge features a sleek perimeter-lighted black dial with stylish white and blue graphics. It offers a black aluminum bezel with a burnished leaning edge, a contoured white pointer, and a flat glass lens. The size 2 gauge requires a 2.0625" (53 mm) mounting hole.

• perimeter-lighted black dial with a contoured white pointer
• stylish graphics
• black aluminum bezel with burnished edge
• flat glass lens
• "size 2 gauge requires a 2.0625" (53 mm) mounting hole"
• Fit type: Universal

User questions & answers

Question:	Is this for 12 volts
Answer:	Yes
Question:	will this meter work with AGM batteries
Answer:	it basically just reads voltage so if battery is putting out { I think} 12.8 it sais full
Question:	I need to know the cut out hole size for this battery guage. mine is
Answer:	2 1/16 is the right size 2 no fit 2 1/8 to big
Question:	Is this guage water proof
Answer:	I don't know. I installed it on my boat, it has been in the rain, has not fogged up and still working..
